Quosures?

Quosures first showed up on the scene as part of rlang about three years ago to a collective 🤯. There is good and bad 🤯, and quosures delivered both in spades. The good: what they do is powerful, and how they do it at a minimum seems magical. The bad: new terminology and mechanics confused a lot of people. Since then the developers have devoted substantial time and effort to make quosures and rlang in general more accessible.

Whether you love or hate rlang, one thing I would hope all but the surliest amongst us would agree on is that quosures are interesting.

This post is not a tutorial for rlang, and it is not endorsed by the rlang authors. It is about understanding what quosures are, what makes them interesting, and how they work in the context of rlang. Quosures started off as a prominent part of rlang, but have more recently been relegated to something closer to “implementation detail” status. They remain central to rlang, but are no longer emphasized in the documentation. Since usage of rlang in this post is expressly for the purposes of understanding quosures, it deviates from current recommended rlang practices¹.

Preface: Carriages, Horses, and Damn Philosophers…

mean_call <- function(expr) {
  cmd2 <- quote(mean(NULL))     # create unevaled `mean(NULL)`
  cmd2[[2]] <- substitute(expr) # sub in user expression
  cmd2
}
(expr <- mean_call(a + b))

mean(a + b)

a <- 1
b <- 2
eval(expr)

[1] 3

bquote(mean(.(1 + 2)))

mean(3)

quote(mean(1 + 2))

mean(1 + 2)

mean_call2 <- function(expr) {
  bquote(mean(.(substitute(expr))))
}
mean_call2(a + b)

mean(a + b)

mean_call2a <- function(expr) {
  quote(mean(substitute(expr)))
}
mean_call2a(a + b)

mean(substitute(expr))

mean_call2(a + b)

mean(a + b)

a <- 1
num <- 2
local({
  a <- 100
  a + num
})

[1] 102

a + num

[1] 3

About Them Quosures

Just as quote, substitute, and bquote do, quosures capture unevaluated R expressions. We may create them with rlang::quo:

library(rlang)
a <- 1
(qrlang <- quo(a + 1))

<quosure>
expr: ^a + 1
env:  global

Additionally as you can see above, quosures record the environment the expression would have been evaluated in, had it not been captured. Unlike typical unevaluated expressions, quosures do no resolve when they are evaled:

eval(qrlang)

<quosure>
expr: ^a + 1
env:  global

We’ll see why this is in a little bit, but until then we can use eval_tidy to evaluate quosures:

eval_tidy(qrlang)

[1] 2

Things are more interesting with more complex environments. Let’s compare expressions captured with quote vs quo in an ad-hoc environment created with local:

a <- 1
lang <- local({
  a <- 100
  list(
    base=quote(a + 1),
    rlang=quo(a + 1)
  )
})
eval(lang[['base']])

[1] 2

eval_tidy(lang[['rlang']])

[1] 101

Normal quoted language resolves a in the environment in which it is evaled. The quosure instead resolves a in the Evaluation Environment in which it was created. Pretty neat.

Quosures in Functions

Let’s build a simple NSE function to compute means in the context of of a user-supplied data frame. First with base:

mean_in_data <- function(data, expr) {
  expr <- substitute(expr)           # capture user expression
  expr <- bquote(mean(.(expr)))      # wrap it in `mean`
  eval(expr, data, parent.frame())
}

The key features are substitute, which we discussed in the previous post, and evaluation in the Calling Environment with parent.frame() to ensure names used in expr resolve as intended by the user of our function.

We can use it to compute mean engine displacement of mtcars in liters:

l.per.cubic.i <- 2.54^3 / 1000
mean_in_data(mtcars, disp * l.per.cubic.i)

[1] 3.78

Next with rlang:

mean_in_data_rl <- function(data, expr) {
  quosure <- enquo(expr)           # capture user expression
  quosure <- quo(mean(!!quosure))  # wrap it in `mean`
  eval_tidy(quosure, data)
}

mean_in_data_rl(mtcars, disp * l.per.cubic.i)

[1] 3.78

While the parallels between the two implementations are clear when they are juxtaposed, they are not obvious from the function names alone. The rlang authors prioritized their own vision of a meta programming interface over harmonizing with the existing conventions, so we end up with the following oddities:

• rlang::quo is used similarly to base::bquote, but is lexically closer to base::quote, and at same time gives no indication of its special environment capture abilities in its name.
• rlang::enquo is used similarly to base::substitute, but bears no relation to base::enquote. This clash with base::enquote is particularly confusing to me given that the “en” gives no indication of how enquo is different from quo (my personal experience was that the lexical similarity between quo and enquo made it harder to figure out what was going on).
• rlang designates partial evaluation with !! instead of .() as in base, which is probably the most controversial design decision.

There are reasonable arguments for why things ended up how they did³. I know the rlang team devoted a lot of time and effort coming up with names, including trying to work with precedent. But when I look at the result I can’t help but think the balance of priorities is off.

Partly as a result the initial confusion when rlang was first released the authors have shifted to different terminology in its documentation and adjusted the interface somewhat. For example, the “curly-curly” operator was added replace the quo(!!enquo(arg)) pattern so we could have written instead⁴:

mean_in_data_rl2 <- function(data, expr) {
  quosure <- quo(mean({{expr}}))     # notice: no enquo
  eval_tidy(quosure, data)
}

This is a big improvement given it removes the quo/enquo confusion and keeps !! out of sight. We stick to the old method because it mirrors the steps used in base, and it is useful for pedagogical purposes to distinguish between argument substitution and partial evaluation.

Contemporary rlang now also replaces quo() with expr()⁵,

While it’s great the rlang team has responded to feedback and tried to adapt it would have been nice to see a re-convergence towards existing R terminology rather than toward Standard Seventeen⁶.

So why bother with rlang, if all I’m going to do is belly-ache about function names? Well, along with the lexical malpractice (I kid, I kid) we get some very interesting features.

The Power Of Quosures

Bad NSE implementations often break when some of the names in an expression are not uniquely mapped in the global environment. Let’s try to trigger failures by complicating the Evaluation Environment:

l.per.cubic.i <- 1                 # decoy
local({
  l.per.cubic.i <- 2.54^3 / 1000   # not global, real duck
  list(
    base=mean_in_data(mtcars, disp * l.per.cubic.i),
    rlang=mean_in_data_rl(mtcars, disp * l.per.cubic.i)
  )
})

$base
[1] 3.78

$rlang
[1] 3.78

A particularly poor implementation might have pulled in the l.per.cubic.i we added to the global environment, but neither is fooled here. Let’s raise the stakes a bit:

l.per.cubic.i <- 1                      # decoy
local({
  mean <- function(x) -base::mean(x)    # decoy
  l.per.cubic.i <- 2.54^3 / 1000
  list(
    base=mean_in_data(mtcars, disp * l.per.cubic.i),
    rlang=mean_in_data_rl(mtcars, disp * l.per.cubic.i)
  )
})

$base
[1] -3.78

$rlang
[1] 3.78

😱! We find the wrong mean. This would have happened even if we had defined our function in a package. The very trick that allowed us to find the correct l.per.cubic.i (eval in parent.frame()) stabbed us in the back. rlang’s version on the other hand works fine. Ultimately the issue is that in the expression generated by mean_in_data*:

mean(disp * l.per.cubic.i)

We need mean to be resolved according to the Function Environment, but disp * l.per.cubic.i in the data enclosed by the Calling Environment. R, however, does not allow more than one Environment Chain at a time.

With quosures, which retain the Evaluation Environments they are defined in, it works right out of the box. Of course we can fix the R version by pre-resolving mean as we did in the prior post, but that’s extra work. What sorcery allows quosures to evaluate a single expression in multiple environments, when R itself does not allow it?

Is It Magic?

Let’s peek behind the curtain:

class(quo(a + b))

[1] "quosure" "formula"

unclass(quo(a + b))

~a + b
attr(,".Environment")
<environment: R_GlobalEnv>

Quosures are formulas, which we can see both from the class, and also from the tilde (~), once we side-step the quosure print method. Formulas are an odd duck in the R world: a form of self-quoting expression that also captures the Evaluation Environment in which it is created. Mostly they are used to implement domain specific languages such as model or plot specifications. Because they can contain arbitrary R expressions as well as environments they are appealing as a vehicle for quosures.

They do have a big draw-back for our purpose: the quoting is triggered by the ~, but the ~ remains in the captured expression.

~a + b

~a + b

This means you cannot evaluate the captured expression as evaluating it just leads to the expression quoting itself again! It’s like those awful trick candles you just can’t blow out:

eval(~a + b)

~a + b

eval_tidy does something quite clever to force evaluation: it replaces ~ with an internal version that self-evaluates quosures. Here is a hack re-implementation to demonstrate the concept:

eval_tidyish <- function(expr) {
  env <- new.env(parent=parent.frame())
  env[['~']] <- function(...) {# replace `~` with our version
    call <- sys.call()
    env <- environment(call)   # recover formula env from call
    eval(call[[2]], env)
  }
  eval(expr, env)
}

eval_tidyish creates an environment that contains a self-evaluating version of ~, and evaluates the expression therein. We can recover the formula environment from the call to the formula, which is fortunate as otherwise this trick would not work. Let’s try it:

a <- 10
q1 <- local({
  a <- 1/2
  ~ a * 2
})
q1

~a * 2
<environment: 0x7f9c8795b498>

eval_tidyish(q1)

[1] 1

With more emotion:

q2 <- local({
  a <- 1/8
  ~ a + 1/8
})
bquote(.(q1) / .(q2))

(~a * 2)/~a + 1/8

eval_tidyish(bquote(.(q1) / .(q2)))

[1] 4

eval_tidyish(bquote(.(q1) / .(q2) + a))

[1] 14

Half-assed quosures! These don’t even support adding data to the Environment Chain, deity-forbid using a formula as a formula, and they’ll give you a severe case of operator-precedence-anxiety. But we do bottle that multiple-Environment-Chain magic in a handful of lines of code.

Aside: eval_tidyish will evaluate quosures, albeit with a once-per-session warning:

eval_tidyish(quo(1 + 2))

[1] 3

Quosures au Naturel

Formulas seem like a natural fit for quosure-like objects, but they are not. Their resistance to evaluation forces a custom evaluator along with a additional logic to preserve non-quosure ~ behavior, which even then remains subtly affected in corner cases⁷. There is also the recovery of the formula environment from the call stack, which works but feels a bit uncomfortable to me⁸.

But R doesn’t offer any other functions that hold unevaluated expression and Enclosures, so what are we to do? Cheat, duh.

In the previous post we solved the two Environment Chain dilemma by pre-resolving the function along one Environment Chain and embedding the result in the otherwise unevaluated expression. The key learning is that it is possible to embed non-language objects in expressions. It’s not even really cheating. R does this as it evaluates expressions, evaluating leaves in the expression tree until the tree is fully evaluated and the result is returned.

Which leads us to⁹:

quote_w <- function(x) {
  caller <- parent.frame()           # must be outside `bquote`
  bquote(with(.(caller), .(substitute(x))))
}

quote_w(a + 1)

with(<environment>, a + 1)

What the hell is that? It’s an unevaluated call to with with an alive-and-kicking environment embedded as the data argument. That means that when we evaluate the expression, the provided sub-expression will be evaluated in the context of that environment. Let’s try it out:

a <- 10
q1 <- local({
  a <- 1/2
  quote_w(a * 2)
})
q1

with(<environment>, a * 2)

eval(q1)

[1] 1

We successfully captured the a <- 1/2 from the local environment, even though we evaluated the expression in the top-level environment where the mapping is a <- 10.

Let’s up the difficulty:

q2 <- local({
  a <- 1/8
  quote_w(a + 1/8)
})
(q3 <- bquote(.(q1) / .(q2)))

with(<environment>, a * 2)/with(<environment>, a + 1/8)

eval(q3)

[1] 4

Each of the a’s is resolved in its own environment. We can even mix them with normal unevaluated expressions. The names outside of the withs resolve in the Evaluation Environment:

(q4 <- bquote(.(q1) / .(q2) + a))

with(<environment>, a * 2)/with(<environment>, a + 1/8) + a

eval(q4)

[1] 14

Why bother with this madness when we have quosures already? Well, it’s fun. And the with approach has benefits:

• We can use good-old base::eval.
• Semantics are pure; everything behaves exactly as usual in the R interpreter.
• Complete interoperability with existing meta-programming constructs (e.g. bquote).
• WYSIWYG: the semantics of the expressions are transparent. Any useR familiar with with knows what the expressions will do. Sure, they don’t necessarily know what’s in the environments, but that’s true of quosures too.
• WYSIWYG 2: We don’t need any special print methods, and operator precedence is crystal-clear.

All of this in two lines of code! It does say something about the baked in meta-programming capabilities of R that such thing is even possible.

Yes, some will object to the aesthetics of the with calls everywhere, preferring the more demure ^ prefix, but the latter relies on custom print methods. We could add the same, but they are defeated by things such as:

q5 <- quo(a + 1)
rlang::expr(a + !!q5)

a + ~a + 1

Of course, we’re not even close to replacing the full functionality of quosures with this, but it’s not a bad start.

Bells, Whistles

substitute_w <- function(x) {
  caller <- parent.frame()
  caller2 <- sys.frame(sys.parent(2))   # see appendix for explanation
  expr <- eval(bquote(substitute(.(substitute(x)),.(caller))))
  expr <- eval(bquote(.(bquote)(.(expr))), caller2)
  bquote(with(.(caller2), .(expr)))
}

mask <- function(expr, data) {
  if(is.language(expr) && length(expr) > 1L) {
    # modify `with` expressions that contain a live environment
    if(expr[[1L]] == as.name('with') && is.environment(expr[[2L]])) {
      expr[[2L]] <- list2env(data, parent=expr[[2L]])
    }
    # recurse on each sub-expression
    expr[2L:length(expr)] <- lapply(expr[2L:length(expr)], mask, data)
  }
  expr
}

      expr[[2L]] <- list2env(data, parent=expr[[2L]])

q6 <- local({
  a <- 1/2
  quote_w(a + b + 2)
})
b <- 1
eval(q6)

[1] 3.5

q7 <- mask(q6, list(b=10))
eval(q7)

[1] 12.5

Endgame

Now we can go back to our mean_in_data* functions:

mean_in_data_w <- function(data, expr) {
  expr <- bquote(mean(.(substitute_w(expr))))
  expr <- mask(expr, data)
  eval(expr)
}

l.per.cubic.i <- 1                      # decoy
local({
  mean <- function(x) -base::mean(x)    # decoy
  l.per.cubic.i <- 2.54^3 / 1000
  list(
    base=mean_in_data(mtcars, disp * l.per.cubic.i),
    rlang=mean_in_data_rl(mtcars, disp * l.per.cubic.i),
    base_w=mean_in_data_w(mtcars, disp * l.per.cubic.i)
  )
})

$base
[1] -3.78

$rlang
[1] 3.78

$base_w
[1] 3.78

Beauty.

Notice we use bquote to generate the mean call. This is safe to do because we evaluate expr in the same environment that call is created so we do not need to capture the local environment¹¹.

Finally, for good measure, we’ll wrap all our functions inside another function to demonstrate argument forwarding.

mean_in_data_all <- function(data, expr) {
  l.per.cubic.i <- 1                    # decoy
  mean <- function(x) -base::mean(x)    # decoy
  list(
    base=eval(bquote(mean_in_data(data, .(substitute(expr))))),
    rlang=mean_in_data_rl(data, !!rlang::enquo(expr)),
    base_w=mean_in_data_w(data, .(substitute_w(expr)))
  )
}

If you look closely you’ll notice that the base approach requires us to capture the user expression and forward it on by using eval(bquote(.(substitute(expr)))). On the other hand, for both the _rl and _w versions we can rely on the functions to do the partial evaluation of their arguments directly.

In and of itself once you’re comfortable with “programming on the language” this is only a slight annoyance, but the result is wrong:

l.per.cubic.i <- 2.54^3 / 1000
mean_in_data_all(mtcars, disp * l.per.cubic.i)

$base
[1] -231

$rlang
[1] 3.78

$base_w
[1] 3.78

The naive implementation picks up both the decoy mean and l.per.cubic.i. This is a variation on the issue we had previously, in which we need different parts of the composite expression evaluated in different environments. With a little extra work, we can resolve this too, but it is nice we can build tools that handle the complexity for us.

Equivalently for the rlang option we could have done mean_in_data_rl(data, {{expr}})

Conclusions

This post is a side-effect of my trying to understand quosures in detail. The base R versions are intended as self-confirmation that indeed, I more or less get the concepts, at least enough to implement variations with (pun-intended) useful properties. I have no intention of publishing a meta programming package with quosure-like functionality. If you are tempted to use the code herein for your purposes, be aware that the testing I did is incomplete and the code has not been used outside of this post¹².

Does this mean I endorse rlang for meta-programming purposes? There are interesting and useful features therein, the overall quality of the package is excellent, and it has no run-time dependencies. One important feature that likely cannot be implemented efficiently in base R is enquos due to dots (...) potentially resolving to multiple environments. Situations with extensive meta-programming involving ... argument forwarding will benefit most from rlang.

My main reservation is the philosophy underlying the API which in my view prioritizes an internal aesthetic at the expense of harmony with the existing meta-programming facilities. Additionally, while the existing facilities are not perfect, they are still excellent, so I’m ambivalent about the feature / complexity trade off that come with rlang.

Appendix

a <- 10
q5 <- local({
  q <- bquote_w(a + .(a))
  a <- 1/2   # assign to `a` AFTER bquote_w!
  q
})
q5

with(<environment>, a + 10)

eval(q5)

[1] 10.5

bquote_w <- function(x) {
  caller <- parent.frame()
  expr <- eval(bquote(.(bquote)(.(substitute(x)))), caller)
  bquote(with(.(caller), .(expr)))
}

a <- b <- 2
expr <- local({
  a <- 1
  bquote_w(a + .(b))
})
expr
eval(expr)

bquote_w <- function(x) { caller <- parent.frame()

  # Capture user expression

  expr <- substitute(x)                 # expr == a + .(b)

  # Wrap the expression in `bquote`, using `bquote`.  We in-line `bquote`
  # so in reality if you examined `expr` below you would see the entire
  # `bquote` function definition crammed into the first element of
  # the expression.  This is necessary to avoid interference with a user
  # defined `bquote`.

  expr <- bquote(.(bquote)(.(expr)))     # expr == (<bquote>)(a + .(b))

  # Evaluate the `bquote` expression we created, in the calling frame so
  # that the elements that need to be partially evaluated are

  expr <- eval(expr, caller)             # expr == a + 2

  # Generate the quoted with

  bquote(with(.(caller), .(expr)))      # with(<caller>, a + 2)
}

a <- b <- 2
f <- function(x) substitute_w(x)
expr <- local({
  a <- 1
  f(a + .(b))
})
expr

with(<environment>, a + 2)

eval(expr)

[1] 3

substitute_w <- function(x) {
  # capture environments, we need the Calling Environment, and the
  # Calling Environment of the Calling Environment

  caller <- parent.frame()
  caller2 <- sys.frame(sys.parent(2))

  # Capture the user expression by running substitute in the caller
  # frame. We inline the substitute function diretly into the
  # expression to avoid conflicts with a possible user-defined
  # `substitute`

  expr <- substitute(x)                  # x
  expr <- bquote(.(substitute)(.(expr))) # (<substitute>)(x)
  expr <- eval(expr, caller)             # a + .(b)

  # Do the partial evaluation in the caller of the caller, see the
  # bquote_w breakdown above for details

  expr <- bquote(.(bquote)(.(expr))) # (<bquote>)(a + .(b))
  expr <- eval(expr, caller2)        # a + 2
  bquote(with(.(caller2), .(expr)))  # with(<caller2>, a + 2)
}

Session Info

sessionInfo()

R version 4.0.2 (2020-06-22)
Platform: x86_64-apple-darwin17.0 (64-bit)
Running under: macOS Mojave 10.14.6

Matrix products: default
BLAS:   /Library/Frameworks/R.framework/Versions/4.0/Resources/lib/libRblas.dylib
LAPACK: /Library/Frameworks/R.framework/Versions/4.0/Resources/lib/libRlapack.dylib

locale:
[1] en_US.UTF-8/en_US.UTF-8/en_US.UTF-8/C/en_US.UTF-8/en_US.UTF-8

attached base packages:
[1] stats     graphics  grDevices utils     datasets  methods   base

loaded via a namespace (and not attached):
 [1] Rcpp_1.0.4.6    bookdown_0.18   digest_0.6.25   later_1.0.0
 [5] mime_0.9        R6_2.4.1        jsonlite_1.6.1  magrittr_1.5
 [9] evaluate_0.14   blogdown_0.18   stringi_1.4.6   rlang_0.4.7
[13] rstudioapi_0.11 promises_1.1.0  rmarkdown_2.1   tools_4.0.2
[17] servr_0.16      stringr_1.4.0   httpuv_1.5.2    xfun_0.13
[21] compiler_4.0.2  htmltools_0.4.0 knitr_1.28
